1532ES Electric Scissor Lift
1532ES Electric Scissor Lift. Patented Powerlift2 elevating system - built strong and works tough; Large sheet loading entrance accommodates 48(1.22 m) material.
Quote Only
Industrial Access Equipment
Hydraulic Scissor Lift
Hydraulic Scissor Lift. Capacity: 1000 lbs. (supports up to four persons); Power Source: 120 Volt AC with thermal overload protection (DC option available for added flexibility).
Personnel Scissor Lifts Quote-based pricing
- Rated Capacity: 1000 lbs. (supports up to four persons)
- Power Source: 120 Volt AC with thermal overload protection (DC option available for added flexibility)
- Platform Safety: Features a fully enclosed platform with 42" guardrails, midrails, 4" toeboards, and a swing-in gate for safe entry and exit.
- Spacious Platform: The 3' x 8' platform is equipped with a serrated grating deck for secure footing, minimizing slip risks.
- Built-in Ladder: A convenient ladder allows easy access to the platform when fully lowered.
Get pricing & availability
Expert help choosing the right configuration.
Spec guidance • Industrial use cases
Type
Personnel Scissor Lifts
Capacity
1000 lbs. (supports up to four persons)
Category
Man Lifts & Aerial Work Platforms
Key Feature
Rated Capacity: 1000 lbs. (supports up to four persons)
Product description
Hydraulic Scissor Lift is specified with capacity: 1000 lbs. (supports up to four persons); power source: 120 Volt AC with thermal overload protection (DC option available for added flexibility).
Introducing the Hydraulic Scissor Lift Man Lift —a powerful, reliable solution designed for elevated tasks that demand stability, safety, and efficiency.
Perfect for industrial and commercial applications, this scissor lift combines advanced safety features with heavy-duty performance to ensure operators can work confidently at height.
Key Whether you're working on maintenance, installations, or other elevated tasks, the Hydraulic Scissor Lift Man Lift provides unmatched safety and performance.
With its robust design, ease of use, and compliance with industry safety standards, it's the ideal choice for lifting personnel to greater heights with confidence.
For Hydraulic Scissor Lift, the catalog lists Capacity: 1000 lbs. (supports up to four persons); Power Source: 120 Volt AC with thermal overload protection (DC option available for added flexibility); Rated Capacity: 1000 lbs. (supports up to four persons). Match these details to the configuration being quoted; options and model variants may differ.
Product features
- Rated Capacity: 1000 lbs. (supports up to four persons)
- Power Source: 120 Volt AC with thermal overload protection (DC option available for added flexibility)
- Platform Safety: Features a fully enclosed platform with 42" guardrails, midrails, 4" toeboards, and a swing-in gate for safe entry and exit.
- Spacious Platform: The 3' x 8' platform is equipped with a serrated grating deck for secure footing, minimizing slip risks.
- Built-in Ladder: A convenient ladder allows easy access to the platform when fully lowered.
- Enhanced Stability: Boxed scissor members and oversize cross-axles reduce platform sway, providing a stable workspace at height.
- Ease of Mobility: Sturdy rectangular base frame with non-marking 8" swivel casters, equipped with wheel and swivel locks for effortless movement.
- Self-Storing Outriggers: Outriggers provide maximum stability (optional on lower-height models).
- Leveling Jacks: Secure the unit on uneven surfaces, standard on models with deck heights above 15' (optional for lower heights).
- Precision and Safety: Bubble levels indicate proper leveling, ensuring safe operation on all surfaces.
- High Visibility: The unit is finished in Safety Orange, making it easily visible in busy work environments.
- Operator Controls: For optimal safety, platform controls require both hands to change elevation, while emergency stops are available on the platform and at the base for quick shutdowns.
Selection considerations
- Confirm required working position and equipment reach.
- Confirm combined operator, tool and material load.
- Confirm floor or ground conditions, access width and overhead obstructions.
Access and lifting
Specifications
Readable, scan-friendly specs for fit and capacity.
| Category | Personnel Scissor Lifts |
|---|---|
| Capacity | 1000 lbs. (supports up to four persons) |
| Power Source | 120 Volt AC with thermal overload protection (DC option available for added flexibility) |
Technical data & configurations
Compare the listed model and configuration details. Confirm current specifications with the documentation supplied for your quote.
| Item# | Working Height | Platform | Outriggers | Weight | Quote | |
| Min. | Max. | |||||
| HW1-7 | 13' | 2'4'' | 7'4'' | not needed | 1700 | Call |
| HW1-10 | 16' | 5' | 10'1'' | not needed | 1800 | Call |
| HW2-13 | 19' | 3' | 12'10'' | not needed | 2000 | Call |
| HW2-16* | 21' | 5'8'' | 15'8'' | required | 2100 | Call |
| HW3-19* | 24' | 3'7'' | 18'8'' | required | 2300 | Call |
| HW3-22** | 27' | 6'4'' | 21'4'' | required | 2400 | Call |
| HW4-24** | 30' | 4'1'' | 24'4'' | required | 2700 | Call |
| HW4-27** | 33' | 6'8'' | 27' | required | 2800 | Call |
| * add 20" to 4-ft base width for outriggers ** add 40" to 4-ft base for outriggers | ||||||
| Optional Equipment | ||||||
| Air-Hydraulic Power Option...... | Call | |||||
| DC Portable Battery Power Option...... | Call | |||||
| Cantilevered Platform extending from deck for added platform length Option...... | Call | |||||
